AHD reversing camera with motorised flap, IP69K

DBC 1240108S AHD

Compact AHD (1080p) colour camera with motorised protective flap

request product find a merchant

  • Compact AHD (1080p) colour camera with motorised shutter

    • No separate shutter control required - the motorised shutter opens as soon as the power supply is applied
    • Smart IR technology with IR LEDs for good visibility in the dark (0 lux)
    • Built-in microphone
    • Integrated heating
    • Viewing angle 110°
    • Maximum moisture protection with IP69K
    • Stainless steel mounting bracket and protective cover
    • Power supply 10-32V

    • 1.29", 2 megapixel CMOS image sensor
    • Resolution: 1920x1080
    • Video system: AHD-PAL, 1080p
    • High light sensitivity up to 0 lux thanks to IR LEDs
    • Viewing angle: 110°
    • Built-in microphone
    • Signal / noise ratio: > 81 dB
    • Automatic, electronic iris
    • Vibration resistant up to 10 G
    • Shock resistance 100 G
    • Power consumption: max 220mA
    • Operating temperature: -30 °C to 70 °C
    • Dimensions (WxHxD) 85 x 71 x 61 mm
    • Weight: approx. 310g
    • DBC 1240108S - Camera
    • WPC 6 - 20m camera cable
  • Download
Technical changes and errors excepted.
